1 1/2" (24B) British Standard pitch sprockets. Manufactured in cast iron
24B-1 45T Cast Iron Sprocket (12SR45C)
24B-1 45T Cast Iron Sprocket (12SR45C)
| Part No. | 7828-132 |
| Code | 12SR45C |
| No. teeth | 45 |
| Outside dia. de | 561.2 |
| Pitch dia. dp | 546.2 |
| Boss dia. | 140 |
| Bore D1* | 45 |
| Overall Width A | 90 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
