1 " (16B) British Standard pitch sprockets. Manufactured in Steel EN8, 080M40/080M46, C45
16B-1 9T Steel Sprocket (8SR9)
16B-1 9T Steel Sprocket (8SR9)
| Part No. | 7826-348 |
| Code | 8SR9 |
| No. teeth | 9 |
| Outside dia. de | 85 |
| Pitch dia. dp | 74.27 |
| Boss dia. | 50 |
| Bore D1* | 16 |
| Overall Width A | 35 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
