5/8" (10B) British Standard pitch sprockets. Manufactured in cast iron.
10B-1 95T Cast Iron Sprocket (5SR95C)
10B-1 95T Cast Iron Sprocket (5SR95C)
| Part No. | 7824-330 |
| Code | 5SR95C |
| No. teeth | *95 |
| Outside dia. de | 488.5 |
| Pitch dia. dp | 480.14 |
| Boss dia. | 100 |
| Bore D1* | 23 |
| Overall Width A | 56 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
