SPZ 4 Groove V Pulleys taper bore for use with our taper bushes.
Spz200/4 V Pulley For 2517 T/L Bush (SPZ200/4)
Spz200/4 V Pulley For 2517 T/L Bush (SPZ200/4)
| Part No. | 7804-713 |
| Type | SPZ200/4 |
| Diameter P (mm) | 200 |
| Diameter O (mm) | 204 |
| Style | 6 |
| Bush | 2517 |
| Bore ø max. | 60 |
| E | 8 |
| J | 171 |
| K | 3.5 |
| L | 45 |
| M | 3.5 |
| N | 124 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
