SPZ 4 Groove V Pulleys taper bore for use with our taper bushes.
Spz224/4 V Pulley For 2517 T/L Bush (SPZ224/4)
Spz224/4 V Pulley For 2517 T/L Bush (SPZ224/4)
Part No. | 7804-714 |
Type | SPZ224/4 |
Diameter P (mm) | 224 |
Diameter O (mm) | 228 |
Style | 6 |
Bush | 2517 |
Bore ø max. | 60 |
E | 14 |
J | 195 |
K | 3.5 |
L | 45 |
M | 3.5 |
N | 124 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
