Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.
Pulley P42L075F, With Pilot Bore (P42L075F)
Pulley P42L075F, With Pilot Bore (P42L075F)
| Part No. | 7801-068 |
| Code | P42L075F |
| Material | Steel |
| Type | 1F |
| No. Teeth | 42 |
| Dp | 127 |
| De | 127 |
| Df | 135 |
| Dm | 70 |
| F | 25.4 |
| L | 38 |
| Bore | 11 |
| No. Flanges | 2 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
