Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.
Pulley 96L075, With Pilot Bore (P96L075)
Pulley 96L075, With Pilot Bore (P96L075)
Part No. | 7801-089 |
Code | P96L075 |
Material | Cast Iron |
Type | 4 |
No. Teeth | 96 |
Dp | 291 |
De | 290 |
Df | |
Dm | 75 |
F | 25.4 |
L | 45 |
Bore | 14 |
No. Flanges | 0 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
