Medway XPA2180 Cogged V-Belt
Raw Edge Cogged Wedge Belts are high performance and are designated by letters standing for their cross-section, e.g. SPAX followed by a number e.g. 1600 which specifies the belts pitch length Lp in mm. They enable; resistance to repeated flexing, compact drives, reduced weight, cost savings, small pulley diameters and high drive ratios. They are manufactured in the cross-sections SPZX (XPZ), SPAX (XPA), SPBX (XPB) and SPCX (XPC) and are static conductive to ISO1813.
Specification
- Code: XPA2180
- Manufacturer: Medway or similar brand
- Width (mm): 12.7
- Depth (mm): 10
- Outside length (mm): 2198
- Pitch length (mm): 2180
- Pitch Length (in): 85.8
- Inside length (mm): 2135
- Inside length (in): 84.1
- Pitch between bands (mm banded type only): -
