Cast iron square flange bearing housing complete with steel bearing insert
UCF 207 35mm, 4-Bolt Square Flange Bearing (UCF/207)
UCF 207 35mm, 4-Bolt Square Flange Bearing (UCF/207)
| Part Number | 7910-006 |
| Code | UCF/207 |
| UCF | 207 |
| Bore (mm) | 35 |
| l | 117 |
| r | 92 |
| v | 19 |
| e | 15 |
| t | 34 |
| F | 14 |
| m | 44.4 |
| A | 42.9 |
| w | 17.5 |
| Bearing No. | UC207 |
| Bolt size | M12 |
| Housing No. | F207 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
