Cast iron square flange bearing housing complete with steel bearing insert
UCF 206 30mm, 4-Bolt Square Flange Bearing (UCF/206)
UCF 206 30mm, 4-Bolt Square Flange Bearing (UCF/206)
| Part Number | 7910-005 |
| Code | UCF/206 |
| UCF | 206 |
| Bore (mm) | 30 |
| l | 108 |
| r | 83 |
| v | 18 |
| e | 13 |
| t | 31 |
| F | 12 |
| m | 40.2 |
| A | 38.1 |
| w | 15.9 |
| Bearing No. | UC206 |
| Bolt size | M10 |
| Housing No. | F206 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
