Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.
Pulley 72L075, With Pilot Bore (P72L075)
Pulley 72L075, With Pilot Bore (P72L075)
| Part No. | 7801-083 |
| Code | P72L075 |
| Material | Cast Iron |
| Type | 4 |
| No. Teeth | 72 |
| Dp | 218 |
| De | 218 |
| Df | _ |
| Dm | 75 |
| F | 25.4 |
| L | 45 |
| Bore | 14 |
| No. Flanges | 0 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
