Timing Pulleys H150 (0.5" / 12.7mm pitch) for 38.1mm (1.5") wide belt. Taper bore for use with our taper bushes. Manufactured in steel or Cast Iron with steel flanges.
Pulley 60H150/9A For 2012 T/L Bush (T60H150)
Pulley 60H150/9A For 2012 T/L Bush (T60H150)
| Part No. | 7800-968 |
| Code | T60H150 |
| Material | Cast Iron |
| Type | 12 |
| No.teeth | 60 |
| Bush | 2012 |
| Dp | 242.55 |
| De | 69241.2 |
| Df | |
| Dm | 106 |
| Di | 223 |
| F | 46 |
| S | 32 |
| R | 7 |
| No. flanges | |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
