Plastic Timing Pulleys MXL025 (0.080" / 2.032mm pitch). Moulded with no insert or grub screw. Polycarbonate - Glass Filled.
Plastic 48MXL025 Type C 8mm Bore (PP48MXL025M)
Plastic 48MXL025 Type C 8mm Bore (PP48MXL025M)
| Part No. | 7800-643 |
| Code | PP48MXL025M |
| Type | C |
| No.teeth | 48 |
| Dp | 31 |
| De | 30.53 |
| Df | 35 |
| Dm | 17 |
| Fw | 8 |
| L | 17.5 |
| Bore(d) | 8 |
| Pw | 11.2 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
