Medway AVX13X1000 Cogged V-Belt
Energy saving, higher performance thanks to their flexibility. Automotive V-belts with a higher performance level have a longer service life. Special designs with Raw edges that allow higher slipping resistance even when they are working with low installation tensions. Maximum resistance to the action of heat and oils. High antistatic properties used in automotive applications and conforming to ISO1813. Part numbers are identified by 3 letters (e.g.AVX) the belts cross section and a 2 digit number (e.g.10)the belts top width and a 3 or 4 digit number which represents the belts length in mm. AVX10x800 etc.
Specification
- Code: AVX13X1000
- Manufacturer: Medway or similar brand
- Width (mm): 13
- Depth (mm): 8
- Outside length (mm): 1000
- Pitch length (mm): 982
- Pitch Length (in): 38.7
- Inside length (mm): 937
- Inside length (in): 36.9
- Pitch between bands (mm banded type only): -
