Aluminium Pulley 28T MXL025F, With Pilot Bore (P28MXL025F)

£8.48
(£10.18 UK, incl VAT)
7800-015
10 g
1-3 Working Days
+
Add to wish list
Aluminium MXL pulleys with zinc plated steel flanges. Pitch 0.080" (2.032mm).. These pulleys are supplied with a pilot bore that can be machined out to a larger accurate diameter (subject to boss size) although many users find the pilot bore quite acceptable. The machining facilities at Gears and Sprockets are limited to smaller gears, those we can machine will have the relevant options available in drop down boxes on the product page. See the 'Custom Machining' tab where applicable on the product page for more information.

Aluminium Pulley 28T MXL025F, With Pilot Bore (P28MXL025F)

Part No.7800-015
CodeP28MXL025F
Type1F
No. Teeth28
Dp18.11
De17.6
Df25
Dm11
F11
L16
Bore (d)3
No. Flanges2
Gs–
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
