British Standard sprockets with integral bearings (INA) for use as an idler.
16B 12T Idler Sprocket INA Bearing (I8SR12I)
16B 12T Idler Sprocket INA Bearing (I8SR12I)
Part No. | 7830-212 |
Code | I8SR12I |
No. teeth | 12 |
Pitch | 1? x 17.02 |
de | 109 |
dp | 98.14 |
A | 16.2 |
D1* | 20 |
F | 47 |
B | 14 |
H | 17.7 |
Bearing | INA |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
