Timing Pulleys H100 (0.5" / 12.7mm pitch) for 25.4mm (1") wide belt. Taper bore for use with our taper bushes. Manufactured in steel or Cast Iron with steel flanges.
Pulley 28H100/5F For 1610 T/L Bush (T28H100F)
Pulley 28H100/5F For 1610 T/L Bush (T28H100F)
Part No. | 7800-939 |
Code | T28H100F |
Material | Steel |
Type | 9F |
No.teeth | 28 |
Bush | 1610 |
Dp | 113.19 |
De | 111.82 |
Df | 120 |
Dm | |
Di | 90.5 |
F | 32 |
S | 25 |
R | 7 |
No. flanges | 2 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
