Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.
Aluminium Pulley 48T XL037 (P48XL037)
Aluminium Pulley 48T XL037 (P48XL037)
| Part No. | 7801-241 |
| Material | P48XL037 |
| Code(Aluminium) | P48XL037 |
| Type | 3 |
| No. Teeth | 48 |
| Dp | 78 |
| De | 77 |
| Df | |
| Dm | 45 |
| F | 14.3 |
| L | 25 |
| Bore(d) | 10 |
| No. Flanges | 0 |
Every effort is taken to ensure the accuracy of the table data
Design variations and errors although rare may occur
